Pink Funnel Icon in SOLIDWORKS: How to Get Rid of It

SOLIDWORKS Pink Selection Filter

Are you tired of seeing the pink funnel icon in SOLIDWORKS? This feature is intended to be helpful, but it can quickly become annoying when you do not need or want to use it. Fortunately, there are several ways to get rid of this pesky icon and reclaim your workspace. In this article, we will provide tips and tricks to disable the pink funnel icon in SOLIDWORKS so that you can focus on your designs without any distractions.

What is the pink funnel icon in SOLIDWORKS?

The pink funnel icon in SOLIDWORKS indicates that a Selection Filter is active. This filter allows you to quickly select specific elements of your model by type, size, material, or any other criteria. For example, you may want to select all the edges in your design. With the Selection Filter active, the pink funnel icon will appear in the lower right corner of your cursor.

When the selection filter is active in SOLIDWORKS, it restricts your selections to certain objects. This is great for selecting just what you want in a crowded area and allows you to control what you select when box selecting or selecting all with Ctrl-A. For example, if you want to select all edges in your design, then the Selection Filter will limit your selection capabilities and only allow you to select edges. Unsure if an object is a solid body or a surface body? Try selecting it with a body selection filter.

Selection Filter Toolbar

How to Disable the Pink Funnel Icon in SOLIDWORKS

There are three ways to disable the pink funnel icon in SOLIDWORKS. First, if you right-click in the graphics area, you can change the selection filter in the context menu. Secondly, if you want to disable all selection filters, you can select the three white filters (or press F6). Thirdly, you can add the selection filter to your active toolbars by clicking on Insert in the drop-down menus, then selecting toolbars and Selection Filter. You can toggle this toolbar on and off by pressing F5. (Remember, you might need to use your Fn key as well on a laptop).

One way to disable the pink funnel icon quickly and easily in SOLIDWORKS is by using the F6 keyboard shortcut or right-clicking. This shortcut will immediately clear any active Selection Filters, allowing you to select any item within your model without restriction. This is especially helpful if you are working on a complex design with many different types of parts or assemblies.

Another way to disable the pink funnel icon in SOLIDWORKS is by using the Selection Filter dialog box. This can be accessed by selecting Tools > Selection Filter from the top menu bar or by pressing F5 on the keyboard. Once you have opened this dialog box, you can deselect any active filters and then click OK to clear the icon.

Finally, you can also disable the pink funnel icon in SOLIDWORKS by right-clicking on the icon and selecting “Clear Selection Filter” from the drop-down menu. This will immediately clear any active filters and disable the annoying pink funnel icon. Right-Click on SOLIDWORKS filter



Tips for Keeping Your SOLIDWORKS Workspace Clean and Distraction-Free

Now that you know how to disable the pink funnel icon in SOLIDWORKS quickly, here are some tips for keeping your workspace clean and distraction-free.

Take advantage of SOLIDWORKS’ selection-based commands. These commands allow you to select objects within your model based on certain criteria quickly. For example, you can select all connected edges in your design using the Select Loop command accessed by right-clicking an edge.

Finally, keep in mind that the pink funnel icon can be helpful. While it may be annoying at times, the pink funnel icon can be used to quickly select specific elements of your design with just a few clicks.

View toolsbar selection filter

Final Thoughts on Disabling Annoying Features in SOLIDWORKS

The pink funnel icon in SOLIDWORKS can be a helpful feature, but it is easy to get annoyed when you do not need or want to use it. Fortunately, there are several ways to disable the pink funnel icon quickly and easily in SOLIDWORKS so that you can focus on your designs without any distractions.

By taking advantage of selection-based commands in SOLIDWORKS and organizing active filters effectively, you can keep your workspace clean and free from unnecessary clutter. With these tips, you will have all the tools necessary to ensure that annoying features like the SOLIDWORKS pink funnel icon no longer disrupt your workflow!
